Shelly PLUS 1

• LAN, Wi-Fi, and Bluetooth connection

• 2 outputs, 16A each. Total device maximum of 25A

• Power metering on each channel and free storage data

• Cover (roller) control - roller shutters, awnings, gates, barriers, sliding doors, curtains, garage doors, bi-directional AC motors

• 1-phase control

• Easy control through the Shelly app, various protocols, and platforms, as well as voice assistants

Specifications

PHYSICAL

• Size (HxWxD): 37x42x16 ±0.5 mm / 1.46x1.65x0.63 ±0.02 in

• Weight: 26 g / 0.92 oz

• Mounting: Wall console

• Screw terminals max torque: 0.4 Nm / 3.5 lbin

• Conductor cross section: 0.5 to 1.5 mm² / 20 to 16 AWG

• Conductor stripped length: 5 to 6 mm / 0.20 to 0.24 in

• Shell material: Plastic

• Color:Blue

ENVIRONMENTAL

• Ambient temperature:

• -20 °C to 40 °C / -5 °F to 105 °F

• Humidity 30 % to 70 % RH

• Max. altitude 2000 m / 6562 ft

ELECTRICAL

• Power supply: 110 - 240 VAC / 24 - 48 VDC / 12 VDC ±10%

• Power consumption: < 1.2 W

OUTPUT CIRCUITS RATINGS

• Max switching voltage AC: 240 V

• Max switching voltage DC: 30 V

• Max switching current AC: 16 A

• Max switching current DC: 10 A

SENSORS, METERS

• Temperature sensor: Yes

RADIO

• RF band: 2400 - 2495 MHz

• Max. RF power: <20 dBm

• Wi-Fi protocol: 802.11 b/g/n

• Wi-Fi Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)

• Bluetooth Protocol: 4.2

• Bluetooth Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)

MCU

• CPU: ESP32

• Flash: 4 MB

FIRMWARE CAPABILITIES

• Schedules: 20

• Webhooks (URL actions): 20 with 5 URLs per hook

• Scripting: mJS

• MQTT: Yes

• CoAP: No
